Medium Duty Racking

Medium-sized racks, utilizing hexagon openings, rack unit on each floor load is by and large between 200 ~ 800KG, the all-out load doesn’t surpass 5000KG

Description

Medium-sized racks, utilizing hexagon openings, rack unit on each floor load is by and large between 200 ~ 800KG, the all-out load doesn’t surpass 5000KG. Rack unit range is typically not more than 2.5M, profundity close to 1M, tallness by and large under 3M. Laying of steel plate or board-level, the establishment is straightforward. Medium racks for manual stacking tasks for capacity of light obligation, little things: generally utilized in the field of hardware, clothing, medication, food, power provider warehousing, circulation focuses, and other cross-line power providers.

Medium duty shelving rack with step beam and steel decking:

Step beam size: 50*30*25*T1.2/1.5mm,60*40*28*T1.2/1.5mm,

80*50*28*T1.2/1.5mm,110*50*28*T1.2/1.5mm

Steel decking: T0.6, 0.7, 0.8 and T1.0mm

Medium duty shelving rack with tube beam and flushing decking:

50*30*T1.2/1.5mm,60*40*T1.2/1.5mm,

80*40*T1.2/1.5mm,100*50*T1.2/1.5mm

Flushing decking: T1.0, 1.2 and T1.5mm

Medium duty shelving rack with tube beam and wire mesh decking:

50*30*T1.2/1.5mm,60*40*T1.2/1.5mm,

80*40*T1.2/1.5mm,100*50*T1.2/1.5mm

Wire mesh decking: Mesh: 100*50mm, Wire: 4.5mm, 3/4/5 ribs, T1.5/1.8mm
